PLUS ET/X-PLUS/X-PLUS ET/X-PLUS WITH STO (SIL3) FUNCTION/X-MIND/HI-MOD

100x100!_plus-ether

PLUS ET

Model Name Drive Type Bus Voltage Range (Volt.) Phase Current Range (Amp.) Dimensions (mm.) Suggested Motors (Flange size)
PLUS ET A3 EtherCAT 39 – 85 VDC 6.0 Box 152 x 129 x 46 mm Plug_in connectors NEMA 23, 60 mm, NEMA 34
PLUS ET B3 EtherCAT 28 – 62 VAC 6.0 Box 152 x 129 x 46 mm Plug_in connectors NEMA 23, 60 mm, NEMA 34



100x100!_325372_xplusb4_1_1

X-PLUS

Model Name Drive Type Bus Voltage Range (Volt.) Phase Current Range (Amp.) Dimensions (mm.) Suggested Motors (Flange size)
X-PLUS B4 STEP/DIR 110 – 230 SUPPLY DIRECLTY FROM THE MAIN 2.4 – 4.0 Box 152 x 129 x 46 mm Plug_in connectors NEMA 34 (with rating for high voltage)
X-PLUS B4.1 STEP/DIR ADVANCED 110 – 230 SUPPLY DIRECLTY FROM THE MAIN 2.4 – 4.0 Box 152 x 129 x 46 mm Plug_in connectors NEMA 34 or bigger (with rating for high voltage)
100x100!_xplus-et

X-PLUS ET

Model Name Drive Type Bus Voltage Range (Volt.) Phase Current Range (Amp.) Dimensions (mm.) Suggested Motors (Flange size)
X-PLUS ET B4 EtherCAT 110 – 230 SUPPLY DIRECLTY FROM THE MAIN 4.0 Box 169 x 129 x 46 mm Plug_in connectors NEMA 34 (with rating for high voltage)





100x100!_xplus-s4

X-PLUS WITH STO (SIL3) FUNCTION

Model Name Drive Type Bus Voltage Range (Volt.) Phase Current Range (Amp.) Dimensions (mm.) Suggested Motors (Flange size)
X-PLUS S4 STO 110 – 230 SUPPLY DIRECLTY FROM THE MAIN 2.4 – 4.0 Box 152 x 129 x 46 mm Plug_in connectors NEMA 34 (with rating for high voltage)
X-PLUS S4.1 STO 110 – 230 SUPPLY DIRECLTY FROM THE MAIN 2.4 – 4.0 Box 152 x 129 x 46 mm Plug_in connectors NEMA 34 (with rating for high voltage)





100x100!_325369_xmb4_1_1

X-MIND

Model Name Drive Type Bus Voltage Range (Volt.) Phase Current Range (Amp.) Dimensions (mm.) Suggested Motors (Flange size)
X-MIND B4 STEP/DIR 110 – 230 SUPPLY DIRECLTY FROM THE MAIN 2.3 – 4.0 Box 180 x 173 x 53 mm Plug_in connectors NEMA 34 – NEMA 42 (with rating for high voltage)
X-MIND B6 STEP/DIR 110 – 230 SUPPLY DIRECLTY FROM THE MAIN 3.4 – 6.0 Box 180 x 173 x 53 mm Plug_in connectors NEMA 34 – NEMA 42 (with rating for high voltage)
X-MIND K4 PROGRAMMABLE 110 – 230 SUPPLY DIRECLTY FROM THE MAIN 2.3 – 4.0 Box 180 x 173 x 53 mm Plug_in connectors NEMA 34 – NEMA 42 (with rating for high voltage)
X-MIND K6 PROGRAMMABLE 110 – 230 SUPPLY DIRECLTY FROM THE MAIN 3.4 – 6.0 Box 180 x 173 x 53 mm Plug_in connectors NEMA 34 – NEMA 42 (with rating for high voltage)







100x100!_hi-mod-new

HI-MOD

Model Name Drive Type Bus Voltage Range (Volt.) Phase Current Range (Amp.) Dimensions (mm.) Suggested Motors (Flange size)
HI-MOD B STEP/DIR 32 – 75 VDC —- —- —-
HI-MOD E CANopen 32 – 75 VDC —- —- —-
HI-MOD A CANopen 32 – 75 VDC —- —- —-
HI-MOD ET EtherCAT 32 – 75 VDC —- —- —-
